3 Ways DRO Mill Drill Machine Semi Automatic With Table Feed And 550 Mm Arm Travel

Name: 3 Ways DRO Mill Drill Machine Semi Automatic With Table Feed And 550 Mm Arm Travel
Brand: QIANGLI
Price: 1 USD

Wholesale 3 Ways DRO Mill Drill Machine Semi Automatic With Table Feed And 550 Mm Arm Travel from china suppliers

Delivery Time : 30 days

Place of Origin : CHINA

Milling Cutter Type : Angle Milling Cutter

Controlling Mode : Artificial

Table Feed.(X/Y/Z) : 30-750/20-500/15-375

Structure : Rocker

Automatic Grade : Semiautomatic

Milling Cutter Structure : Indexable Type

Table Travel(X/Y/Z) : 750/320/460

Machine Color : Customizable

Brand Name : QIANGLI

Certification : ISO CE

MOQ : 1 SET

Price : Negotiable

Packaging Details : Export Packaging

Payment Terms : T/T

Contact Now

3 Ways DRO Drill Mill Machine With Table Feed ,550 mm Arm Travel

Specifications:

Specifications	Unit	XL6332		XL6332C		XL6332CL
Table size	mm	1325×320				1600×320
Table travel (X/Y/Z)	mm	750/320/460		1100/320/450		1300/320/450
Table feed. (X/Y/Z)	mm/min	30-750/20-500/15-375
Table rapid speed (X/Y/Z)	mm/min	1200/800/600
Spindle taper		7:24 IS050 (H) 7:24 IS040 (V)
Stroke of spindle quill	mm	127 (V)
Distance between spindle nose and table surface	mm	200-660	200-650
Distance between horizontal spindle center line and table surface	mm	20-480	20-470
Distance between horizontal spindle center line and arm surface	mm	245
Spindle speed range	r.p.m	16steps 60-1800 (H) 8steps 65~4660 (V)
T-slots(NO./width/pitch)	mm	3/18/70
Arm travel	mm	550
Main motor power	Kw	5.5 (H) 3.7 (V)
Torque of X/Y/Z axis AC servo motor	N.m	10
Overall size	mm	1800×2100×2500	2245×2100×2500		2520×2100×2500
Net weight	kg	2685	2750		2800

STANDARD ACCESSORIES

DRILL CHUCK END MILL CHUCK MILL CHUCK TOOL BAR SPINDLE ARBOR

OPTIONAL ACCESSORIES

DRO UNIVERSL DIVIDING HEAD ROTARY WORK TBALE CLAMPING KIT

3 Ways DRO Mill Drill Machine Semi Automatic With Table Feed And 550 Mm Arm Travel

Packaging & Shipping

(XL6332) Milling machine in metal work

PACKING: WOODEN CASE,PLASTIC COVER INSIDE

PACKING SIZE: 1720*1520*2225mm

G.W/N.W: 1900/1770KGS

CONTAINER: 14SETS IN 1X40GP

Our Services

Customized services

We accept customized services around the world

Afer-sale services

1. Technical support online service provided.

2. Technical files service provided.

3. Spare parts replacement and repair service provided.

4. Questions will be replied within 24 hours
